Outdoor Telecom Power System - The Automation Ghana Group

Reliable Power Solutions Tailored for Your Outdoor Telecom Needs

Your telecom base stations deserve the best in power management, especially in challenging outdoor environments. At Automation Ghana Group, we understand the unique demands of your operations, which is why we’ve developed an Outdoor Telecom Power System specifically for you. Our solution integrates high-efficiency rectifiers, intelligent controllers, and advanced thermal cooling within a durable, IP55-compliant cabinet — all designed to keep your equipment running smoothly and efficiently, no matter the weather conditions.

High-Efficiency Rectifiers:
Experience reduced energy loss and improved performance with our high-efficiency rectifiers. You’ll benefit from lower energy costs while ensuring your network operates reliably around the clock.
Intelligent Controllers:
Stay in control with real-time monitoring and adaptive management. Our smart controllers optimize power usage based on your actual needs, providing you with peace of mind and minimizing unnecessary costs.
Advanced Thermal Cooling System:
Protect your equipment with our advanced thermal cooling system, designed to maintain optimal internal temperatures and extend the lifespan of your infrastructure.
IP55 Compliance:
Rest easy knowing your equipment is safe from the elements. Our IP55-rated cabinet prevents water penetration and dust ingress, ensuring consistent performance in even the most challenging outdoor conditions.

Technical Data

Rectifiers:
- Efficiency: Up to 96%
- Output Voltage: 48V DC
- Output Power Range: 1.2 kW to 6 kW per rectifier module
- Input Voltage Range: 90–300V AC
- Power Factor Correction: >0.99
Intelligent Controllers:
- Monitoring: Real-time power consumption, temperature, and system health
- Communication Protocols: SNMP, Modbus, RS-232/485
- Alarm Management: Configurable alarms for overvoltage, undervoltage, and system faults
- Remote Access: Web-based interface, mobile app compatibility
Thermal Cooling System:
- Type: Active cooling (forced ventilation)
- Operating Temperature Range: -40°C to +75°C
- Cooling Capacity: Up to 5,000 BTU/hr
- Noise Level: <55 dB(A)
IP55-Compliant Enclosure:
- Material: Galvanized steel with anti-corrosion coating
- Ingress Protection: Dust-tight, water-jet resistant
- Dimensions: Customizable (Typical: 1800 x 800 x 600 mm)
- Weight: 100–200 kg, depending on configuration
- Mounting Options: Pole-mount, wall-mount, or ground-mount
Battery Management System:
- Battery Type Supported: VRLA, Li-ion
- Battery Capacity: 100 Ah to 500 Ah
- Charging Current: 0–50A (adjustable)
- Temperature Compensation: -3 mV/°C per cell
Surge Protection Devices:
- Voltage Rating: 230/400V AC
- Response Time: <25 nanoseconds
- Maximum Surge Current: 40 kA
DC Distribution Panels:
- Voltage Rating: 48V DC
- Current Rating: 10A to 200A per circuit
- Circuit Breakers: Thermal-magnetic type, resettable
